Each page under the Anatomy - KINE 2031 section (Lab 2, Lab 3 etc) will provide extra resources to help you with your studying and review of the lab material covered in this course. There are pictures of each muscle covered as well as each muscle's origin, insertion, and function.

Legend (For all Labs): O = Origin - Proximal attachment of a muscle (Closer to midline of body)

                                       I = Insertion - Distal attachment of a muscle (Further away from midline of body)

                                      F = Function/Action - The function/action of the muscle at the joint(s)/articulation(s) it is attached to



*WARNING – THIS IS SUPPLEMENTARY INFORMATION – STUDY FROM COURSE KIT FOR EXAMS*



Lab 2 - Upper Body Torso + Shoulder Girdle

  Chest Musculature:    Blue: Xiphihumeralis    Yellow: Pectoralis Minor    Green: Pectoralis Major    Red: Pectoantebrachialis

Chest Musculature:

Blue: Xiphihumeralis

Yellow: Pectoralis Minor

Green: Pectoralis Major

Red: Pectoantebrachialis

  Xiphihumeralis - Not In Humans

Xiphihumeralis - Not In Humans

  Pectoralis Minor    O -
Outer surface of ribs (2/3-5)                                      I -
Coracoid process of scapula   F -
Abduction and inferior rotation of scapula

Pectoralis Minor

O - Outer surface of ribs (2/3-5)

I - Coracoid process of scapula

F - Abduction and inferior rotation of scapula

  Pectoralis Major   O -
Clavicle (head and medial portion) and costal cartilage of ribs 1-6  I -
Greater tubercle and bicipital groove of humerus  F -
Shoulder flexion, Adduction and medial rotation of humerus, Horizontal flexion
of arm

Pectoralis Major

O - Clavicle (head and medial portion) and costal cartilage of ribs 1-6

I - Greater tubercle and bicipital groove of humerus

F - Shoulder flexion, Adduction and medial rotation of humerus, Horizontal flexion of arm

  Pectoantebrachialis - Not in Humans

Pectoantebrachialis - Not in Humans

  Latissimus Dorsi - Posterior View   O - Vertebrae T7-L5, Crests of sacrum, and inferior 4 ribs  I - Bicicptal groove of humerus  F - Shoulder extension, Adduction and medial rotation of humerus

Latissimus Dorsi - Posterior View

O - Vertebrae T7-L5, Crests of sacrum, and inferior 4 ribs

I - Bicicptal groove of humerus

F - Shoulder extension, Adduction and medial rotation of humerus





  Latissimus Dorsi - Anterior View

Latissimus Dorsi - Anterior View

  Trapezius - Reflected   O -
Occipital bone, Ligamentum nuchae, Spines of thoracic vertebrae (C7 – T12)  I -
Clavicle, Acromion process and Spine of scapula  F - Superior
Fibres: Elevation and superior rotation of scapula. Middle Fibres: Adduct scapula. Inferior
Fibres: Depress scapula and aid in superior rotation with superior fibres

Trapezius - Reflected

O - Occipital bone, Ligamentum nuchae, Spines of thoracic vertebrae (C7 – T12)

I - Clavicle, Acromion process and Spine of scapula

F - Superior Fibres: Elevation and superior rotation of scapula. Middle Fibres: Adduct scapula. Inferior Fibres: Depress scapula and aid in superior rotation with superior fibres

  Blue: Latissimus Dorsi - Not Reflected    Yellow:  Trapezius - Not Reflected

Blue: Latissimus Dorsi - Not Reflected

Yellow:  Trapezius - Not Reflected

  Serratus Anterior   O -
Lateral surface of 8 upper ribs  I -
Medial border and anterior surface of scapula  F - Abduction and superior rotation of scapula

Serratus Anterior

O - Lateral surface of 8 upper ribs

I - Medial border and anterior surface of scapula

F - Abduction and superior rotation of scapula

  Rhomboids   O -
Spinous process of C7-T5  I -
Medial border of scapula  F -
Adduction and inferior rotation of scapula

Rhomboids

O - Spinous process of C7-T5

I - Medial border of scapula

F - Adduction and inferior rotation of scapula
